10/100/1000M 1SFP to 2RJ45 External Power Supply Mini Gigabit Media Converter

Press Esc key to close this popup
  • 10/100/1000M 1SFP to 2RJ45 External Power Supply Mini Gigabit Media Converter

10/100/1000M 1SFP to 2RJ45 External Power Supply Mini Gigabit Media Converter

Product Item: #293
P/N: MFMC-1SFP-2RJ45G
Starting at: US$44.67

Please Choose:






Order Today, Ship before 04/02/2024, from U.S. or HK
  • Description
  • Datasheet
  • Tags

Mini Gigabit Media Converter 10/100/1000M 1SFP to 2RJ45



Media converters can be used anywhere in the network to integrate newer technology with existing equipment to support new applications, technologies and future growth. Instead of costly, across-the-board upgrades, media converters can extend the productive life of the existing cabling as well as the active equipment.

Fiber-Mart.COM supply 10/100Base Ethernet Fiber Media Converters, 1000Base Gigabit Fiber Media Converter,SFP Fiber Media Converter, Options in singlemode dual fiber, multimode dual fiber and singlemode single fiber. We also supply Media Coverter Chassis, the 1U height 12 slots media converter rack mount chassis specially designed for accommodating chassis-based mini Media Converters



Features

  • AutoCross™: Automatically detects and configures the twisted pair port on the converter to the correct MDI or MDI-X configuration.
  • Link Pass Through: Link Pass Through is a troubleshooting feature that allows the media converter to monitor both the fiber and copper RX ports for loss of signal.
  • Automatic Link Restoration: The media converters will automatically re-establish link in all network conditions.
  • Selectable speed setting: The converter can be set to 10Mbps or 100Mbps or 1000Mbps. Both copper and fiber ports are automatically set to the same speed. Devices connect to duplex mode of link partner.
  • Jumbo Frames is available for the 10/100/1000M media converter with 1 RJ45 port + 1 fiber port. Any questions, please feel free to contact us at [email protected] for more details.



Key Features

  • 10/100/1000Base-TX UTP to 1000Base-FX fiber media convertion
  • Support one SFP Fiber port and two RJ-45 ports
  • Support IEEE802.3, IEEE802.3Z media convertion
  • Choice of SC/LC SFP connectors for multimode and singlemode
  • DIP switch to set different configurations
  • Compact package size
  • The mini 10/100/1000Base-TX to 1000Base-FX (also can be forced to 100Base-FX) media converter is fully compliant with IEEE802.3, IEEE802.3Z 1000Base-TX/FX protocols. The converter is equipped with one SFP fiber port and two RJ-45 ports as switch function
  • A DIP switch is placed at the bottom of the case. Depend on different configurations, the user can set the different operating mode (Force FX to 100M, jumbo frame up to 9KB, port based isolation)



Applications:

10/100/1000M Ethernet Network Distances
It use the 10/100/1000BASE-T to 1000BASE-X speed setting (back-to-back) to extend the distance between two 1000BASE-T devices up to 80km. using single mode fiber without a repeater.



Technical Specifications

Data Rates 10/100/1000Mbps
(IEEE802.3, IEEE802.3Z 1000Base-Tx)
1000Mbps (1000Base-FX) or 100Mbps (100Base-FX)
Input Power Requirements:
Input voltage DC 5-12V
Power consume 3 Watts maximum
Environmental Conditions:
Operating temperature 0℃ to 40℃
Cooling free air convection
Storage temperature -20℃ to +85℃
Operating Humidity 90% max, non-condensing
Mechanical Specifications:
Case Material Iron
Case Color Black
Net Weight 150g approx. /unit
Dimensions 60 (W) x 20 (H) x 90 (L) (mm)



Label Customized

Note: We can design Fiber Media Converter label for your company according to your requirements. Print any logo in the label is for free. If you need to print your company logo on the equipments, MOQ is 1000pcs.
please contact [email protected] for more details.
