1x2 DWDM CH45-CH60 Red/Blue C Band Filter with Steel Tube Package, Single Mode LC/UPC
Fiber-MART 1x2 DWDM Red/Blue Band Filter is a passive micro optics device based on environmentally stable thin film filter technology. It is mainly used to separate or combine Red band wavelength signals and Blue band wavelength signals in C Band, in single fiber Bi-directional DWDM systems and high power amplification system . The components are characterized with wide passband, low insertion loss, high return loss, excellent environmental stability and high power handling capability.
Product Details
Pass Band Wavelength Range |
1529.35 - 1541.55nm(CH45-CH60) |
Reflect Band Wavelength Range |
1548.31 1560.81nm(CH21-CH36) |
Insertion Loss (Pass Band) |
0.3dB |
Insertion Loss (Reflect Band) |
0.4dB |
Isolation (Pass Band) |
25dB |
Isolation (Reflect Band) |
15dB |
Dead Band ( |
