1x24 Opto-Mechanical Optical Switch Modules

Product Item: #1941
P/N: OSM-1x24
Starting at: US$2,304.00

Please Choose:










Order Today, Ship before 04/02/2024, from U.S. or HK
  • Description
  • Datasheet
  • Tags

Optical Switch Modules 1x24 Opto-Mechanical


Fiber-Mart's Bi-directional, fully non-blocking 1x24 Multi-channel optical switch modules is an ideal product where small size and superior optical performance are required. The module functions as switching core of a high-capacity packet switching backbone router. It connects optical channels by redirecting an 1 incoming optical signal into a selected signal from 24 output fiber, suitable for 2RU Rack chassis and Desktop optical switch equipment.

Fiber-Mart offers up to 128 ports optical switch modules. Achieved by using an opto-mechanical configuration activated via an electrical control signal, they offer unparallel advantages of very low loss and cost, very compact, easy to mount, and available in any 1RU Rack chassis, 2RU Rack chassis, 4RU Rack chassis, and Desktop optical switch equipment. They are most affordable high performance optical switch modules with absolute minimal impact on pre-engineered loss budgets. Our optical switch modules are tested in-house prior to shipment to guarantee that will arrive in perfect physical and working condition.

Features
  • 1 x 20 configarations
  • Modularized design
  • Compact size, easy to integrate
  • Ultra-low insertion loss and back reflection
  • Bi-directional operation
  • Fast switching speed
  • Precise repeatability
  • Epoxy-free in optical path
  • Operates with dark or lit fibre
  • High reliability, High stability, High optical isolation
  • Low polarization dependent loss (PDL)
  • Latching and Non-latching for optional
  • Singlemode and Multimode for optional
Applications
  • Ring network
  • OEM system integration
  • ROADM
  • RF over fiber
  • Fibre switching
  • Optical bypass
  • Hybrid OEO/OOO network switches
  • Automated component test and measurement
  • Remote network monitoring & test access
  • Instrumentation grade switching
  • Secure communication networks

Specifications

Parameters Unit OSM-1x24
Insertion Loss dB Typ: 0.8 , Max: 1.0
Wavelength Range nm 532 ~ 1300 1260 ~ 1660
Testing Wavelength nm 532 /650 /780 /850 /980 /1300 1310 /1490 /1550 /1650
Return Loss dB SM ≥ 55 , MM ≥ 35
Crosstalk dB ≥ -80
PDL dB ≤ 0.10
WDL dB ≤ 0.25
TDL dB ≤ 0.30
Repeatability dB ≤ ±0.05
Power Supply v AC 220V or DC 48V
Lifetime Cycle 107
Switch Time ms ≤ 12 (Sequence switch time of adjacent channel)
Optical Input Power mW ≤ 1000
Operating Temperature ° C -20 ~ +70
Storage Temperature ° C -40 ~ +85
Dimension mm 184 x 78 x 66
Housing Options mm 2U 19” rack or Desktop for optional

Note: Special specifications can be customized according to customer requirements.

Optical Route

Timing Diagram

Mechanical Dimensions (Unit: mm)

Note: This picture is 1x16 Optical Switch Modules, pls use this picture for your reference.
Order information: OSM-1xN-A-B-C-D-E-F-G-H-I
Fiber-Mart have extensive expertise in creating custom optical switch modules, to best meet an application specific test requirement. Modules can be made with:
1. Unique combinations of optical switches or other optical components (N≤128)
2. Customer specified fibers
3. Customer specified connectors (Mil-Spec, E-2000, etc.)
4. Performance optimized for customer specified wavelengths



N A B C D E F G H I
Channel Connector Fiber Type Fiber Length Diameter Control Model Wavelength Range Housing Voltage Power
1xN (N≤128) OO: None SM: 9/125um 05: 0.5m 25: 250um L: Latching 85: 850nm None 3: 3V S22: 220V
  FU: FC/UPC M5: 50/125um 10: 1.0m 90: 900um N: Non-Latching 13: 1310nm 1U: 1U19" 5: 5V S48: 48V
  FA: FC/APC M6: 62.5/125um 15: 1.5m 20: 2.0mm S: Special 14: 1490nm 2U: 2U19" S: Special S24: 220V+48V
  SU: SC/UPC S: Special S: Special 30: 3.0mm   15: 1550nm 4U: 4U19"   D22: Double 220V
  SA: SC/APC     S: Special   162: 1625nm T: Desktop   D48: Double 48V
  LU: LC/UPC         165: 1650nm S: Special   S: Special
  LA: LC/APC         13/15: 1310/1550nm
  S: Special         S: Special

For example: OSM-1x24-FU-M6-15-S-L-13-2U-5-S22

For more information about Opto-mechanical fiber optic switches, please e-email [email protected].




Customer Reviews

Displaying 1 to 3 (of 3 reviews)

by Andrew Hassin
Date Added: 09/13/2021
Excellent 1x24 optic switch with mm850nm lc pc connectors, we need it to control by PC rs232, Fibermart made it for us, Thank you!

Rating: 5 of 5 Stars [5 of 5 Stars]
1x24 Opto-Mechanical Optical Switch Modules

by Velislav Nikolov
Date Added: 06/29/2021
Well received 1x24 optic switch with nice performance, it comes with software RS232 TTL control and 5V DC power supply, everything works great!

Rating: 5 of 5 Stars [5 of 5 Stars]
1x24 Opto-Mechanical Optical Switch Modules 1x24 Opto-Mechanical Optical Switch Modules

by Harry
Date Added: 09/25/2019
It's easy to integrate! Fast switching speed!

Rating: 4 of 5 Stars [4 of 5 Stars]
