8 fiber Ribbon Fiber Fusion Splice Protection Sleeves with Double Ceramic 40mm 50pcs/pkg

Product Item: #4644
P/N: FM-4008DR
US$10.80



Order Today, Ship before 04/02/2024, from U.S. or HK
  • Description
  • Datasheet
  • Tags

8 fiber Ribbon Fiber Fusion Splice Protection Sleeves with Double Ceramic 40mm 50pcs/pkg



Description

This products is made up of cross linked polyolefin heat-shrinkable tubes,hote melt tubes and Stainless steel needle. It is specifically designed for the protection of fiber optical closure.


Features

  • Protect connection point,improve the mechanical strength,it is most reliable way to protect the fusion.
  • Esay to operate,reducing the risk of fiber damage during installation
  • Transparent tube,it is easy to see the status of fiber optical closure
  • Min.shrinks temperatuer:120℃,shrink very fast and very easy to installation
  • Work temperature high (-55°C~100°C), widely used
  • Sealing structure let closure have good resistance to temperature and humidity performance.



Ordering Information

Type 4~6 fiber Single Ceramic Bar 4~6 fiber Double Ceramic Bar 8~12 fiber Single Ceramic Bar 8~12 fiber Double Ceramic Bar
Outer Tube Outer Diameter 4.4±0.1 4.8±0.1 5.8±0.1 5.8±0.1
Thickness 0.2±0.05 0.2±0.05 0.25±0.05 0.25±0.05
Length 42.0±1 42.0±1 42.0±1 42.0±1
Material Flexible Polyolefin Flexible Polyolefin Flexible Polyolefin Flexible Polyolefin
Inner Tube Inner Diameter 2.6 x 1.6±0.1 2.6 x 1.6±0.1 3.5 x 2.2±0.1 3.5 x 2.2±0.1
Length 0.3±0.1 0.3±0.1 0.5±0.1 0.5±0.1
Thickness 40.0±1 40.0±1 40.0±1 40.0±1
Material EVA EVA EVA WVA
Ceramic Bar Diameter 3.0±0.2 3.0±0.2 4.0±0.2 4.0±0.2
Length 40.0±0.5 40.0±0.5 40.0±0.5 40.0±0.5
Amount 1 2 1 2
Material 95 Ceramic 95 Ceramic 95 Ceramic



Quantity per package: 50pcs/pkg

Note: We also provide this kind of protection sleeves with 1000pcs/pkg and good price.

Fiber optic splice protection sleeves are used for optical fiber fusion protection, it can protecting and supporting the fusion splice point. Fiber-Mart.com now provides different sizes and materials of this kind of products. And if you can not find the fiber optic splice sleeves you need on our website, welcome to contact us, we will give you a reasonable suggestion.


Item Test method Performance
Temperature IEC216 -55°C~100°C
Tensile strength ASTM D 2671 18MPa
Elongation at break ASTM D 2671 700%
Density ISO R1183D 0.94g/cm3
Dielectric strength IEC243 25kV/mm
Volume resistance IEC243 1015Ω
Dielectric constant IEC243 2.5
Longitudinal change ASTM D 2671 ±5%
Eccentricity ASTM D 2671 105


Datasheet to Download
