MPO to MPO Singlemode Waterproof Fiber Optic Patch Cable

Press Esc key to close this popup
  • MPO to MPO Singlemode Waterproof Fiber Optic Patch Cable

MPO to MPO Singlemode Waterproof Fiber Optic Patch Cable

제품 항목: #16384
P/N: FM-12-SM-IP67MPO-IP67MPO
시작 시간: US$120.00

선택해주세요:






Order Today, Ship before 07/10/2022, from U.S. or HK
  • 설명
  • 데이터 시트
  • FAQ
  • 태그

Waterproof Fiber Optic Patch Cable, IP67 MPO to IP67 MPO, Singlemode, 12 Fibers



Waterproof fiber optic patch cables are designed to fit for outdoor applications. The strong PU jacket and armored structure can resist high temperature and suit to use in harsh environment. The cable can provide 1 gigabit data transfer speeds in high bandwidth application and up to 5 times faster than standard 9/125um fiber patch cable. What's more, it's IP67 MPO cable connectors have an extremely rugged, protective rubber coating with integral anti-kink strain-relief boot and a rubber-coated, metal, latching cap, attached by a steel lanyard. When mated or capped, the connection is environmentally sealed up to IP65. It is ideal for using in a variety of applications, including fiber to the antenna (FTTA) and fiber to the home (FTTH).

Fiber-MART provides MPO male (with locating pins) suitable for mounting from the rear in the MPO panel mount connector, and either a 12-core or 24-core fiber to an MPO plug (with locating pins) or socket (without locating pins) 12-core or 24-core connector with mating housing, or to a breakout or fan-out terminated with individual LC, SC, ST or FC connectors. Any customized requirement, please fell free to inform us.


Product Type Waterproof Cable Fiber Type Singlemode OS2 9/125
Connector IP67 MPO Fiber Count 12
Trunk Diameter 4.0mm Branch Diameter 3.0mm
Insertion Loss 0.20dB Return Loss 50dB
Storage Temperature -55C ~85C Operating Temperature -40C ~70C



International Protection (IP) Rating







Features


High temperature stability, low insertion lossWater proof, dust proof and corrosion resistantBump resistance - 4000 bumps @ 40g accelerationEasy operation, reliable and cost-effective installationFree fall resistance - 500 falls onto concrete from 1.2M height





The Application of Waterproof Fiber Optic Patch Cable





IP67 MPO Connectors: socket & plug

There are two types of IP67MPO waterproof connector: IP67MPO plug (with locating pins) and IP67MPO Socket (without locating pins), the plug of one cable and the socket of the other cable can be connected to extend the cable length.



IP67 MPO Component Details

In Fiber-MART, IP67MPO cable connector is the MPO connector whose optical channels are based on the convention with twelve or twenty-four singlemode APC. The aluminum frame has a spring-loaded push-pull locking mechanism and possesses the excellent cable retention because of an aramid yarn within the cable. When there is no connection by the automatically operated sealing-cover, both chassis and connector can protect against dirt and dust. In addition to the automatic sealing shutters, rubber outer sheath and steel, the automatic protective cap is fitted for using when unconnected. When connected or capped, the sealing connection environment amounts to IP67.



Waterproof Optic Patch Cable Performance



Fiber Type Singlemode Multimode
Insertion Loss 0.20dB 0.30dB
Return Loss 50dB 35dB
Storage Temperature -55C ~85C -55C ~85C
Operating Temperature -40C ~70C -40C ~70C
Repetition Test(Additional Loss) 0.1dB 0.1dB
Repetition Test(Return Loss Variability) <5dB <5dB
Temperature Stability(Additional Loss) 0.2dB 0.2dB
Temperature Stability(Return Loss Variability) <5dB <5dB
Bump Resistance 4000 bumps @ 40g acceleration 4000 bumps @ 40g acceleration
Tensile Strength Tensile of 1500N-cable dependent Tensile of 1500N-cable dependent
Free Fall Resistance 500 falls onto concrete from 1.2M height 500 falls onto concrete from 1.2M height




Fibermart MPO Fiber Patch Cable Datasheet







Datasheet to Download
