ODC Plug to ODC Plug 4 Fibers Singlemode Outdoor Cable IP68 ODC-4 Plug to Plug

Press Esc key to close this popup
  • ODC Plug to ODC Plug 4 Fibers Singlemode Outdoor Cable IP68 ODC-4 Plug to Plug
  • ODC Plug to ODC Plug 4 Fibers Singlemode Outdoor Cable IP68 ODC-4 Plug to Plug
  • ODC Plug to ODC Plug 4 Fibers Singlemode Outdoor Cable IP68 ODC-4 Plug to Plug

ODC Plug to ODC Plug 4 Fibers Singlemode Outdoor Cable IP68 ODC-4 Plug to Plug

Product Item: #18024
(0 Customer Reviews)
P/N: ODC-4-SM-PP-X-FM
Starting at: US$68.00

Please Choose:






Order Today, Ship before 06/13/2026, from U.S. or Hong Kong
  • Description
  • Datasheet
  • Tags
  • FAQ

IP68 ODC Plug to ODC Plug 4 Fibers Cable with ODC-4 Outdoor Connector Plug to Plug



Applications

Fibermart ODC connector is next generation connectors for wireless base station application (WCDMA/TD-SCDMA/CDMA200/Wi-MAX/GSM) that can meet the requirements of FTTA (fiber to the top of the tower). We developed ODC connector's base on special connectors craft, our ODC connector's interface can be compatible with the mainstream of the current global supplier of ODC connector.



Features

  • 4 fibers，singlemode or multimode
  • Compact design with 4×1.25mm ferrules
  • Built-in Plug with square or hexagonal flange
  • Extension connector for cable chaining
  • Screwed locking mechanism
  • Easy and safe intallation
  • Water proof,dust proof and corrosion resistant
  • Water proof protection caps
  • EMI protected
  • RoHs compliant
  • Fulfills performance standard IEC 61753-1 Cat.E
  • Cable Length: 1M or custom
  • Connector: ODC Plug to ODC Plug



Specifications



Technology   Full ceramic ferrule and sleeve
Housing material   Nickel plated brass
Mechanical performance ODC plug ≤1000 N tensile load≤30 N static side load
ODC Plug ≤30 N tensile load
Installation torque force min.1Nm max.2Nm
Operating temperature IEC 61300 – 2 - 22 -40℃ up to +85℃
Mating durability   1000 cycle
Ingress protection(mate) IEC60529 Ip 68
Salt mist IEC61300-2-26 30 days passed
Vibration IEC61300-2-1 Pass 10-500Hz/10g
Shock IEC61300-2-9 Pass 100g



Optical Performance

Insertion loss
IEC61300-3-34		 Singlemode Typ. ≤0.30dB 97% ≤0.45dB
Multimode Typ. ≤0.30dB 97% ≤0.50dB
Return loss Singlemode ≥50dB



Mechanical Drawing

Sample Picture

ODC Plug and Socket from FibermartODC-4 Socket



Fibermart ODC-4 Plug Socket Outdoor Fiber Cable Datasheet



Datasheet to Download
