100W 1064nm High Power Collimated Free Space Beam Output Isolator HPCFMI

Press Esc key to close this popup

100W 1064nm High Power Collimated Free Space Beam Output Isolator HPCFMI

Product Item: #506
(0 Customer Reviews)
P/N: HPCFMI-1064-100
Starting at: US$4,000.00

Please Choose:




Connectors:






Order Today, Ship before 06/13/2026, from U.S. or Hong Kong
  • Description
  • Datasheet
  • Tags
  • FAQ

High Power Output Isolator 100W 1064nm Collimated Free Space Beam HPCFMI



Fiber-Mart high power components HPCFMI-1064-100 is 1064nm 100w 3.0mm loose tube HI1060 fiber 1M Output Beam Diameter :8mm。 It also can customize rang from 780nm to 1550nm and handling power from 300mW to 100W or other on request. Low insertion loss, high isolation, high power handling, high return loss, high extinction ratio and excellent environmental stability and reliability.



Characteristics

  • High Isolation& High Power Handling
  • High Extinction Ratio
  • Low insertion Loss & High Return Loss
  • Excellent Environmental Stability and Reliability



Applications

  • Fiber Amplifier
  • Fiber sensor
  • Instrumentation Applications
  • Lab Research



Specifications

Parameters

Unit

Values

Center Wavelength

nm

1064

Operating Wavelength Range

nm

±10

Typ. Peak Isolation

dB

35

Min. Isolation in Band (at 25℃)

dB

30

Min. Transmission

%

90

Nominal Output Beam Diameter

mm

8±1

Max. Peak Power

kW

50

Max. Optical Power (CW)

W

100,200,500

Min. Return Loss

dB

50

Fiber Type

-

LMA-GDF-20/25/30-250 ,20/400 fiber

Fiber Length(B)

m

>1.0

Armoured Length(A)

m

2.5 & 3.0

Tensile Load

kg

1

Operation Temperature

℃

0 ~ +50

Storage Temperature Range

℃

-20 ~ +75



Dimension



Order Information

Item Wavelength Optical Power Fiber Type Package Dimensions Output Beam Diameter Fiber Jacket on Input & Length (A) Fiber Length Connector Type on in&out
HPCFMI-1064-100 1=1064
S=Specify
 		 50=50W
S=Specify		 1=HI1060 fiber
2= LMA fiber
S=Specify		 C–Circle Type
Q–Quadrate Type		 08=8mm
S=Specify		 C25–3mm=Loose Cable&2.5m Length
A25–3mm=3mm Armoured Cable&2.5m Length
B25–6mm=6mm Armoured Cable&2.5m Length		 1=1m
S=Specify		 N=None
S=Specify




Fibermart Optical Isolator Datasheet





Datasheet to Download

Add your Tags

Optical Isolator | Output Isolator HPCFMI |
