1x20 Opto-Mechanical Optical Switch Modules

Optical Switch Modules 1x20 Opto-Mechanical

Fiber-Mart's Bi-directional, fully non-blocking 1x20 Multi-channel optical switch modules is an ideal product where small size and superior optical performance are required. The module functions as switching core of a high-capacity packet switching backbone router. It connects optical channels by redirecting an 1 incoming optical signal into a selected signal from 20 output fiber, suitable for 2RU Rack chassis and Desktop optical switch equipment.

Fiber-Mart offers up to 128 ports optical switch modules. Achieved by using an opto-mechanical configuration activated via an electrical control signal, they offer unparallel advantages of very low loss and cost, very compact, easy to mount, and available in any 1RU Rack chassis, 2RU Rack chassis, 4RU Rack chassis, and Desktop optical switch equipment. They are most affordable high performance optical switch modules with absolute minimal impact on pre-engineered loss budgets. Our optical switch modules are tested in-house prior to shipment to guarantee that will arrive in perfect physical and working condition.

Specifications

Note: Special specifications can be customized according to customer requirements.

Optical Route

Timing Diagram

Mechanical Dimensions (Unit: mm)

Note: This picture is 1x16 Optical Switch Modules, pls use this picture for your reference.
Order information: OSM-1xN-A-B-C-D-E-F-G-H-I
Fiber-Mart have extensive expertise in creating custom optical switch modules, to best meet an application specific test requirement. Modules can be made with:
1. Unique combinations of optical switches or other optical components (N≤128)
2. Customer specified fibers
3. Customer specified connectors (Mil-Spec, E-2000, etc.)
4. Performance optimized for customer specified wavelengths


For example: OSM-1x20-FU-M6-15-S-L-13-2U-5-S22

For more information about Opto-mechanical fiber optic switches, please e-email [email protected].
