48 Ports CAT6 Angled Patch Panel 2U

48 Ports CAT6 Angled Patch Panel 2U

The 19” 1U angled patch panels with 48 ports are perfect for high-density applications such as data centers where optimizing space usage is crucial. The patch cords can be routed directly into vertical cable managers, eliminating the need for horizontal cable management while maintaining the bending radius. The patch panel is available in a completely equipped shielded or unshielded version. Thanks to a special adapter unit it accommodates the widely used, well-proven RJ45 connection module from Fiber-Mart.

Key Features

• Meets or exceeds all CAT6 standards
• Supports T568A and T568B for universal wiring
• Meets the EIA/TIA-310-D rack mount standard
• Ideal for high-density applications
• Includes (4) 10-32 and (4) 12-24 screws
• Forward angle is 128°to provide better cable organization
• Center balanced design provides performance to 250 MHz
• Choose from CAT6 and CAT5e panels with 24 or 48 ports
• Enables cables to flow from vertical cable management channels in an organized fashion
• Rolled-edge, 16-gauge steel construction provides superior strength to eliminate flexing during termination

Specifications

• Overall dimensions: 19”, 1U
• Connectors —Front: (24) RJ-45;Rear: (24) 110 punchdown contacts
• Construction —16-gauge cold, rolled steel
• Nose Contact Material —Beryllium copper with precious metal plating and nickel under-plating
• Wiring —Universal (T568A and T568B)
• Size —3.5"H (2U) x 19"W x 5"D (8.9 x 48.3 x 12.7 cm)
• Weight —2.5 lb. (1.1 kg)

Applications

• Designed for use with CAT6 Patch Cables
• Can be used in vertical cable management
• High-density applications such as data centers
