FM-700A-T Hand-held Fiber Probe

Product Item: #8973
(0 Customer Reviews)
P/N: FM-700A-T
US$862.33



Order Today, Ship before 06/10/2026, from U.S. or Hong Kong
  • Description
  • Datasheet
  • Tags
  • FAQ

FM-700A-T  Hand-held Fiber Probe



Key Features

  • 8 inch TFT-800 LED Desktop Monitor, HD image, no shadow/dark corner/interference
  • All scratch/blot/debris can be viewed and detected
  • Quick navigation, get image within 3-5 seconds; Two-way focus control
  • 95% Image centralization
  • 35 types of adapters tips available to inspect different connectors and angle-mounted connectors with limited access space
  • Precise resolution (<1 μm), no shadow or vignetting in screen
  • Clear image, no interface, no flash
  • Reliable output signal, no default under repeated operation
  • Various monitors can be chosen with specific display capability



Applications



Specification

  • End face inspection for patch cord /bulkhead-mounted equipment/transceiver etc
  • End face inspection of assorted connectors PC/APC,MPO/MTRJ etc
  • Connector inspection in Fiber network/equipment/kits/assembly
Magnification/Resolution 400*/0.75μm(Based on benchmark -8 Inch monitor)
Field of View 0.35mm×0.25mm
Tips Connection Cone contact
Focus way /Range Two-way /<3mm
Output Type PAL or NTSC or USB
Light Source/Life time Coaxial blue LED with 100,000 hrs above
Size/Weight （ mm/kg ） 180*41*36 /0.164
Image Sensor 1/3 Inch 5V Voltage
Temperature -10~60 ℃
Humidity 90% Relative humidity Tolerance, no condenses



Fiber Inspection Probe Datasheet



FVM100 Fiber Probe Scopes Datasheet



FVM103 Fiber Probe Scopes Datasheet





Datasheet to Download
