Single-channel-100M EOC master Outdoor

FM3200W EOC master is single-channel-100M outdoor equipment, with carrying capacity of 253 EOC slaves. It can work in atrocious weather with good stability because of its waterproof and lightproof shell.


Features

  • Good anti-jamming capability with OFDM (kind of MCM, Multi-Carrier Modulation) and channel-adaptive technology
  • Highly adaptable to network, amplifier and distributor
  • Highly effective filter, lower interference to CATV
  • Supply VLAN, IGMP and QoS
  • Support SNMP, WEB and CLI management
  • Support remote software upgrade
  • Support AC220V and AC60V power supply

Specification

System Parameter Technical Index
System Bandwidth Physical layer data rate 224Mbps
CSMA/CA, TDMA(In the Future)
Modulation BSPK, QPSK, 1024/256/64/16/8-QAM, ROBO
MAC Protocol TDMA and CSMA
EOC technology HomePlug AV
Frequency 7.5 ~ 35MHz
Protocol and Standard IEEE 802.1Q
IGMP v1, v2
IEEE 802.1P QoS
NMS WEB; CLI; SNMP
Data Interface/td> One 10/100Base-TX RJ45 input port
Auto MDI/MDIX
Comply with 802.3, IEEE802.3u
TV Interface Two RF ports
Metric thread F type
Output level: 108dBμV
Insertion Loss: <1dB
Impedance: 75Ω
Hybrid Interface One RF hybrid signal output port
Metric thread F type
Frequency: 2-870MHz
Output Level: 108dBμV
Impedance: 75Ω
Light Indicator ETH1 ETH2 (Ethernet port LED)
LINK (link LED)
Sys (system LED) RUN (RUN LED)
PWR (power LED)
Distance >700m
Power AC220V /AC60V
Power Consumption <6W
Dimension 224mm(length) × 200mm(width)× 110mm(height)
Working Temperature -20°C~ +80°C
Storage Temp -25°C~ +75°C
Humidity 20% ~ 85%(non-condensing)
Storage Humidity 10% ~ 90%(non-condensing)
