10/100M/1000M SFP to RJ45 port POE Media Converter

10/100M/1000M SFP to RJ45 port POE Media Converter

The POE (Power Over Ethernet) media converter enables enterprises to provide power to network devices over the existing CAT5 data connection. The 10/100/1000 PoE Ethernet to Fiber Converters provide an economical path to extend the distance of an existing network with fiber cabling. At the same time they function as PoE injectors to power devices like IP phones, video conferencing equipment, IP cameras and Wi-Fi devices over copper UTP cabling.

Fiber-Mart supply 10/100/1000Base Ethernet Fiber Media Converters, 1000Base Gigabit Fiber Media Converter, SFP Fiber Media Converter, Industrial managed Media Converter, Managed Media Converter (Standalone or Card Type), POE media Converter, options in singlemode dual fiber, multimode dual fiber and singlemode single fiber. We also supply Media Converters Chassis, like 14 slot media converter chassis, 16 slot media converter chassis, and 17 slot media converter chassis, used to manage the various media converters.

Key Features

One RJ45 port and one SFP socket ,It can convert Optical-Electric Ethernet signals between 10/100/1000M UTP ports and 1000M optical fiber ports and switch Ethernet signals between port and port.

• 10/100/1000Base-T(X) to 1000Base-FX Fast Ethernet POE Converter
• Built-in AC/DC power supply
• Support VLAN
• Over-current protection
• DIP switch to set different configurations
• LFP (Link Fault Pass-through) support
• Fully complies with IEEE802.3 100Base-T, IEEE802.3u 10/100Base-SX/TX, IEEE802.1q, IEEE802.1p QoS, IEEE802.1d Spanning Tree, IEEE 802.3z, IEEE 802.3ab standard

Applications:

1. Apply to ready to rise to 10M extended enterprise network bandwidth 1000M
2. Apply to images, voice and other multimedia data on an integrated transport network point
3. Applies to the computer signal transmission in need of the occasion widely used for computer data transmission network to meet a variety of business needs
4. Apply to the campus broadband network, broadcasting network and intelligent residential broadband fiber-to-floor fiber to the home data transfer with the switches and other computer network equipment can be combined to form:-chain, star, ring-type network and other computer networks.

Specifications

• UTP port: 1 RJ45
• UTP Rate: 10/100/1000Mbps
• Fiber Rate: 1000Mbps
• Fiber Port: 1 SFP
• Fiber Type: Single-mode& Multimode Fiber
• Power Supply: Built-in
• UTP cable: Cat. 5/5e/6 UTP cable (the max distance up to 100m)
• Light Indicator: POW, FDX, TX Link /ACT, SPD, FX Link /ACT, FDX
• Operation Temperature: 0 ℃~50 ℃(Humidity: 5~90% non-condensing)
• Storage Environment: -20℃ to +85℃(Humidity: 5~90% non-condensing)

Label Customized

Note: Neutral and customized label are available per your requirements, please feel free to contact us at [email protected] for more details.
