12 Fibers Pigtail

Get Reliable 12 Fiber Pigtails from Fibermart in Custom Lengths with LC, SC 0.9/2.0mm Breakouts

The 12 Fiber Pigtail is ideal for high-density connections, with low insertion loss and top-notch performance in tight spaces. For projects that require higher capacity, our 12 LC cable and 12 LC pigtail options help simplify cable management while maintaining excellent performance. On the other hand, the SC pigtail has a simple push-pull mechanism, making it easy to install in various network environments. With 12-fiber pigtail, you can simplify installations and reduce splicing time. These pigtails come with pre-terminated fibers, allowing businesses to form error-free connections in data centers, telecommunications, and enterprise networks.

Introduction

Fibermart 12 Fiber Pigtail is a fundamental termination component in fiber optic infrastructure, serving as the critical, factory-terminated interface that bridges the raw fiber plant with network equipment. Consisting of a short length of optical fiber with a connector on one end and exposed fiber on the other, pigtails enable reliable, low-loss connections through permanent fusion splicing. Available in single-mode and multimode variants (including OM3/OM4), and with a wide range of connectors like LC and SC, these components are engineered to simplify installations in high-density environments such as data centers, telecommunications hubs, and FTTH networks, ensuring signal integrity and operational efficiency.

Features

● Available with LC, SC, FC, and ST connector in UPC/APC. Supports OS2 single-mode (9/125µm) and OM1/OM2/OM3/OM4/OM5 multimode fibers.

● 100% Tested with individual Testing Report, Pre-terminated factory-polished connectors with CE, RoHS, FCC, ISO9001 Certificates.

● Optimized Performance with Featured 0.5um Concentricity Ceramic Ferrules, low insertion loss (≤0.2 dB), high return loss (≥50 dB).

● High-Density and Color-Coded Design: The 12-fiber configuration and individual color-coding simplify management, tracing, and splicing.

● Durable and Flexible Construction: Utilizes a tight-buffered design with a 0.9mm/2.0mm breakout jacket for robust protection and flexibility.

● Broad Environmental Compatibility: Constructed with PVC, LSZH, or OFNP jackets to meet flame-retardant standards for riser or plenum required spaces.

● Industry Standards Compliance: Manufactured and tested in compliance with Telcordia GR-326-Core and RoHS directives, guaranteeing high quality.

Principles

A fiber optic pigtail operates as a permanent extension of the optical fiber plant. Its core function is to provide a superior, fixed connection point where the fragile glass fiber from a main cable is joined to a robust, standardized connector.

The principle centers on creating a continuous optical waveguide with minimal signal loss. This is achieved through fusion splicing, where the exposed, cleaved end of the pigtail's fiber is permanently fused to the corresponding field fiber using an electric arc. This fusion creates a near-seamless glass junction that allows light to pass through with very low attenuation (typically ≤0.1 dB per splice). The connector on the opposite end of the pigtail (e.g., LC or SC) is factory-polished to exacting standards, ensuring optimal alignment and low back-reflection when plugged into an adapter port on a switch, panel, or transceiver. This two-stage process—permanent splice on one end, removable connector on the other—provides a reliable and high-performance link between the passive cabling infrastructure and active network equipment.

Applications

● Data Center Interconnections: Terminating backbone networks and trunk cables in main distribution area (MDA) and equipment distribution area patch panels.

● Telecommunications Central Offices and Cable Headends: Building out fiber distribution frames (FDFs) and splice enclosures for aggregation and distribution.

● Fiber to the Home (FTTH) Networks: Deploying in optical line terminals (OLTs), splitter cabinets, customer premises equipment (CPE) for last-mile connectivity.

● Enterprise Network Backbone and LANs: Facilitating connections in building entrance facilities, telecommunications rooms, between floors for campus networks.

● System Integration and Test Environments: Serving as tailored, ready-to-splice components for prototyping, lab setups, and equipment manufacturing.

Specifications
