1x16 Blockless Fiber PLC Splitter
1x16 PLC Splitter,G.657A Fiber 0.9mm for input and output, FC, SC, LC or ST connectors for choice. Blockless Type PLC Splitter Features
Blockless Type PLC Splitter Applications
Packaging
(Shipping fee is calculated by volume weight)A.Transparent plastic box(As default)
Mechanical Drawing
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
.jpg)
| Parameter | Port Configuration | ||||||
| 1X2 | 1X4 | 1X8 | 1X16 | 1X32 | 1X64 | ||
| Fiber Type | G.657A | ||||||
| Operating Wavelength(nm) | 1260～1650 | ||||||
| Insertion Loss(dB) | Typical | 3.9 | 7 | 10.2 | 13.2 | 16.2 | 19.7 |
| Max | 4.2 | 7.4 | 10.7 | 13.7 | 17.1 | 21.2 | |
| Loss Uniformity (dB) | Max | 0.4 | 0.6 | 0.8 | 1.2 | 1.5 | 2.5 |
| Return Loss (dB) | Min | 50 | 50 | 50 | 50 | 50 | 50 |
| PDL (dB) | Max | 0.2 | 0.2 | 0.3 | 0.3 | 0.3 | 0.4 |
| Directivity (dB) | Min | 55 | 55 | 55 | 55 | 55 | 55 |
| Wavelength Dependent Loss(dB) | Max | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 | 0.8 |
| Temperature Dependent Loss (-40~+85°C) | Max | 0.5 | 0.5 | 0.5 | 0.8 | 0.8 | 1 |
| Operating Temperature (°C) | -40~+85 | ||||||
| Storage Temperature (°C) | -40~+85 | ||||||
Note:
·Above is the parameters for Blockless Fiber PLC Splitter with connectors.
·Without connectors, the insertion loss will be 0.2dB lower.
