2x3 PM780 Polarization Maintaining FBT Fiber Splitter Slow Axis 780nm MPO to MPO FBT PM Fiber Coupler

2x3 PM780 FBT Splitter, PM780 Fiber Coupler, MPO to MPO, Fiber Polarization Maintaining FBT Coupler Splitter Slow Axis w/ Plastic ABS Box Package in 780nm

Polarization Maintaining Planar Light wave Circuit (PLC) splitter is a type of polarization maintaining optical power management device that is fabricated using silica optical waveguide technology. PM PLC splitter maintains polarization of input optical signal. Polarization Maintaining Fiber Splitter is an optical splitter in which the polarization of linearly polarized light waves launched into the fiber is maintained during propagation, with little or no cross−coupling of optical power between the polarization modes.

Fiber-Mart offers a large selection of polarization maintaining (PM) 1xN and 2xN optical splitter, Polarization Maintaining Splitter modules, plc splitter 1x16. PM splitters are supplied in configurations with 2, 4, 8 and plc splitter 1x16 output channels. PM fibers are bonded to the PLC circuit chips using precision multi-fiber alignment techniques. Our splitter modules feature low insertion loss, low polarization dependence and high polarization extinction ratio over a wide wavelength range.

Features

• Wide Band and Operating Temperature
• High polarization extinction ratio
• Good Splitting Uniformity
• Low insertion loss
• The length of pigtail: 1.0m as default(also customized)
• The Axis: Slow Axis as default, Fast Axis is also available

Applications

• Splitting or Combining Output Power of Transmitters Using Polarization Maintaining Fiber
• Excellent for laboratory and industrial applications
• Aerospace and Military Application
• Fiber Sensor
• Fiber Laser
• Test Bed

Mechanical Drawing

2x3: 110*80*18 mm(the picture is 2x16 for reference)

Test Report

The test report will be provided when the products are delivered.
