SMA905-SMA905 Duplex OM4 Fiber Patch Cable

Product Item: #11900
P/N: SMA5-SMA5-DX-OM4-FM
Starting at: US$31.38

Please Choose:


Connector









Order Today, Ship before 06/10/2026, from U.S. or Hong Kong
  • Description
  • Datasheet
  • Tags
  • FAQ

SMA905-SMA905 Duplex OM4 Fiber Patch Cable



The SMA-905 fiber optic patch cord, also known as FMMA connector, was one of the First fiber optic interconnect system that gained industry wide acceptance.SMA905 fiber patch cords make use of threaded connections and is still widely used for military, industrial, medical and Surgical applications and laser systems because of their low cost multimode coupling. It features simple termination and Assembly, and is TIA and IEC compliant. SMA 905 multimode connectors are available with stainless alloy or stainless steel ferrules.



Connector Features

  • 1-4- 36 - UNS thread locking mechanism
  • 3.175 mm cylindrical drivepipe
  • Core diameter:0.126mm 0.23mm
  • The minimum bending radius:10D(D:optical fiber Core diameter)
  • Numerical Aperture:0.4-0.5na
  • Out-Track:2.0mm/3.0mm/2.5mm
  • Insertion loss:0.5db
  • Wavelength:650nm



Applications

  • Transmission with low loss, high transmission rate, high precision
  • Laser surgery
  • Photodynamic Therapy
  • Spectral measurement
  • Laser bonding
  • Illumination
  • Sensor



Make to Order

Connector Type Inner Hole Size Concentricity Roundness Core Material
Metal Ferrule Zirconia Ferrule 0.127~1.200mm ≤3.0μm ≤2.0μm stainless steel cupronickel

Notes:
1 The default ferrule of the connector is Metal Ferrule,please post a inquiry for Zirconia Ferrule. 2 The common size standard of Inner Hole is 127+3/-0μm,please kindly enquiry us for other size standards.

Special Customization Requirements for High Power SMA905-SMA905 Duplex OM4 Dia2.5mm Fiber Patch Cable

Connector Type Tailstock of Connector Bare fiber clamp Ferrule Inside Diameter Concentricity RoundnEss Core Material length
Metal Ferrule With groove Standard (Default) With 127-2000 um ≤5um ≤2um stainless steel 1m, 2m... custom
Without groove (Default)
Zirconia Ferrule Lengthen (custom) Without (Default) cupronickel



Sample Pictures




Custom OEM



Note:
Fiber-Mart is a professional manufacturer and supplier of fiber optic cables. Any customized service is offered here. If you have any special requirements of High Power SMA905 Fiber Patch Cable in accordance with the specification sheet above, please email us to [email protected] or call at +86-01-86-2786-1199.Fiber-Mart will try his best to work out a cost-effective solution for your special requirements.



Specifications

The numerical aperture of the Quartz fiber: 0.22-0.37
Fiber Diameter(mm) 0.2 0.3 0.4 0.5 0.6 0.65 0.8
Minimum Bending Radius 10D (D:optical fiber core diameter)
Fiber Cor(coating layer): 1:1.05 or 1:1.4
Numerical Aperture 0.21-0.37
Transmission(%/m0) Transmission(0.20-0.4um) 85-98
Visible Light(0.4-0.7um) 97-99
Near-Infrared(0.76-1.6um) 90-99
Heliun-Neon(0.6328um) 99
YAG(1.06um) 98
Argon(0.5145um) 98
Transmission Power >130w(fibre [email protected])



Fibermart Fiber Patch Cable Datasheet







Datasheet to Download
