FC/APC Singlemode Fixed Fiber Optic Attenuator Male to Female, 1~25dB Optional

Product Item: #16214

(35 Customer Reviews)

P/N: AT-M-FCA

US$5.20

Please Choose:

Attenuator dB:

Customized Details:

Order Today, Ship before 06/18/2026, from U.S. or Hong Kong

Discount Prices

Quantity	Unit Price	Discount
200-499	US$4.94	5%
500+	US$4.68	10%

Description
Datasheet
Tags
FAQ

FC/APC Fiber Optic Attenuator Fixed, SM/MM Male to Female Attenuator, FC Optical Attenuator

As optical passive devices,Fiber-MART attenuators are mainly used in fiber optic to debug optical power performance & optical instrument calibration correction & fiber signal attenuation to ensure the optical power in a stable and desired level in the link without any changes on its original transmission wave. Buy FC Attenuator, Fiber Attenuator at Fibermart.

Fiber Connector	FC	Ferrule Type	Zirconia Ceramic
Connector Gender	Fixed Male to Female	Transfer Mode	SM/MM
Attenuation	1~25dB	Operating Wavelength(nm)	1260~1620(SM),850 or 1330(MM)
Attenuation Accuracy	1-9dB±0.5dB, 10-25dB±10%	Return Loss	≥45dB
Polarization Dependent Loss	≤0.2dB	Max Optical Input Power	200mW
Humidity	95%RH	Operating Temp Range	-40~80°C
Storage Temp Range	-40~85°C

Highlights

Fixed FC Singlemode Fiber Optic Attenuator, 1~25dB

Precise attenuation values
Low PDL & insertion loss
Precisional reflection polishing

1. Flexiable case for easy portability

Accurate size armed with elegant dust cap, better ensure the handy installation and protection from out-service.

2. Durable metal shell for permanent protection

Shaped with metal material, our attenuators perfectly protect the core insert from external damage.

3. Elaborately designed packing for no-damage delivery

Delicate packaging, convenient for using and well-protected in transit to ensure no-damage delivery.

Attenuator Application

Optical attenuator is a passive device used to reduce the power level of an optical signal. It is generally used in single-mode long-haul applications to prevent optical overload at the receiver. Optical attenuator is widely used in CWDM&DWDM, CATV systems, data center networks, test equipment and other high power applications.

Datasheet to Download
