1x2 Optical Switch Opto-Mechanical Mini BiDi Non-latching 5V

1x2 Opto-Mechanical Bidi Optical Switches, Mini +5V Power Fiber Optic Switch, 1x2 Non-latching

The 1x2 Opto-Mechanical Bi-directional Fiber Optical Switch connects optical channels by redirecting 1 incoming optical signals into 2 output fibers. This 1x2 optical switch is achieved using a opto-mechanical configuration and activated via an electrical control signal. The switch has integrated electrical position sensors.Based on thin film filter technology that provides a robust method of altering the light patch, this series of products has a drastically simplified platform configuration offering high reliability and low production cost. This novel design significantly reduces moving part position sensitivity, offering unprecedented high stability as well as an unmatched low cost. 1x2 fiber latching switch, 1x2 latching switch, 1x2 opto-mechanical switch, buy opto-mechanical 1x2 fiber switch at Fibermart!

Fiber-Mart offers most affordable high performance Opto-Mechanical Fiber 1x2 Optical Switches. Our Mechanical Fiber Optic Switches are tested in-house prior to shipment to guarantee that they will arrive in perfect physical and working condition. Currently configurations includes 1x1, 1x2, 1x4, 1x8, 2x2, 2x2A, 2x2B, and 2x2BA as well as Dual 2x2 and Dual 2x2 Bypass configurations for single mode or multimode fibers. For more information about Opto-mechanical fiber optic switches, please e-email [email protected].

Specifications

Note:
1. All parameters are for device without connectors.
2.Special specifications can be customized according to customer requirements.

Optical Route

Mechanical Dimensions (Unit: mm)

Electrical Driving Requirements

The load is a resistive coil which is activated by applying +5V (draw ~ 40mA). 1x2 Optical Switch Applying too long pulse for the latching version will heat up the device. Fiber-Mart also offers TTL, USB, and RS232 interfaces as an option-please contact Fiber-Mart sales at [email protected].

Functional Diagram

Order information: OSW-1x2－A－B－C－D－E－F－G

Fiber-Mart provides customized design optical switches to meet special control and applications. Also, Fiber-Mart offers modular assemblies that integrate other components to form a full function modules or subsystem. For details, please contact Fiber-Mart at [email protected].

Question:
1. Number of switching ports: 1, 2, 3, 4, 8, or 12.
2. What wavelengths are you using?
3. Which core/cladding size are you using?
4. What type of connectors do you need?
5. How long should the fibers be? What size jacketing?
6. Are there any other special requirements?

For example: OSW-1x2－M6－13－5－L－S－15－FP
