Fiber PLC Splitter 1x6 Blockless Mini-Module Fiber Optic Splitter, 1x6 PLC Splitter, 1x6 Fiber Splitter
1x6 Fiber PLC Splitter, G.657A Fiber 0.9mm for input and output, FC, SC, LC or ST connectors for choice.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
 |
 |
| A | B | C |
Mechanical Drawing
.jpg)
The blockless PLC splitter can realize the effect of 0.9mm loose tube output without using the fanout. It is small volume and easy to use.
V.S FBT Coupler, the advantages of PLC are as follows
- The loss to different wavelength transmission is not sensitive, so it can meet the transmission requirements of different wavelength
- High spectral uniformity, can splitter the signals on average
- Compact structure, small volume
- The cost advantage is very obvious on many splitter channels
Order Information
Fiber-Mart provides a whole series of 1xN and 2xN splitters that are tailored for specific applications:
a.1x2, 1x4, 1x6, 1x16,1x32, 1x64, 2x2, 2x4, 2x8, 2x16, 2x32,2x64 Versions of splitters are available.
b. SC/UPC, FC/UPC, LC/UPC, SC/APC, FC/APC, LC/APC connectors or no connectors can be selected as you like
c. 0.9mm for input and output fiber type.
d. The length of pigtail can be also customized; usually we will provide you 1.5m, welcome to contact us for more details.
- Our Factory
Specifications
| Parameter | Port Configuration | ||||||
| 1X2 | 1X4 | 1x6 | 1X16 | 1X32 | 1X64 | ||
| Fiber Type | G.657A | ||||||
| Operating Wavelength(nm) | 1260～1650 | ||||||
| Insertion Loss(dB) | Typical | 3.9 | 7 | 10.2 | 13.2 | 16.2 | 19.7 |
| Max | 4.2 | 7.4 | 10.7 | 13.7 | 17.1 | 21.2 | |
| Loss Uniformity (dB) | Max | 0.4 | 0.6 | 0.8 | 1.2 | 1.5 | 2.5 |
| Return Loss (dB) | Min | 50 | 50 | 50 | 50 | 50 | 50 |
| PDL (dB) | Max | 0.2 | 0.2 | 0.3 | 0.3 | 0.3 | 0.4 |
| Directivity (dB) | Min | 55 | 55 | 55 | 55 | 55 | 55 |
| Wavelength Dependent Loss(dB) | Max | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 | 0.8 |
| Temperature Dependent Loss (-40~+85°C) | Max | 0.5 | 0.5 | 0.5 | 0.8 | 0.8 | 1 |
| Operating Temperature (°C) | -40~+85 | ||||||
| Storage Temperature (°C) | -40~+85 | ||||||
Note:
·Above is the parameters for Blockless Fiber PLC Splitter with connectors.
·Without connectors, the insertion loss will be 0.2dB lower.
