E2000-E2000 APC Simplex OM4 Multimode E2000 Fiber Patch Cable

Product Item: #7242
P/N: OM4-E20-E20-SX-FM
Starting at: US$5.46

Please Choose:









Order Today, Ship before 06/10/2026, from U.S. or Hong Kong
Discount Prices
Quantity Unit Price Discount
200-999 US$5.19 5%
1,000+ US$4.91 10%
  • Description
  • Datasheet
  • Tags
  • FAQ

E2000-E2000 APC Simplex OM4 50/125 Mulitmode Fiber Patch Cable, E2000 Patch Cable, OM4 E2000 Cable



Fiber Patch Cables also known as fiber jumpers or fiber patch cords.Fiber optic patch cable is one of most commonly used components in fiber optic network. Buy E2000 Cable, OM4 E2000 Cable at Fibermart!
10G fiber optic patch cables provide 10 gigabit data transfer speeds in high bandwidth applications and they are 5 times faster than standard 50um fiber cable. Works with both VCSEL laser and LED sources. Our 10G fiber optic patch cables are 100% optically tested for maximum performance. We have all lengths and connectors available.
And for OM3 50/125 Mulitmode Fiber Patch Cable and OM4 50/125 Mulitmode Fiber Patch Cable, their main difference are as following:
A. OM4 was developed specifically for VSCEL laser transmission and allows 10 Gig /second link distances of up to 550 Meters (compared to 300M with OM3).
B. The effective modal bandwidth for OM4 is more than double that of OM3. For OM4 patch cable, it is 4700 MHz.km while for OM3, it is 2000 MHz.km.



Key Features

  • E2000-E2000 Connectors, APC Default (UPC optional)
  • Multimode Duplex fiber optic cable
  • Micron: 50/125um
  • Complete with Lucent Technologies aqua jacket
  • Bandwidth transmitting rates up to 10 gigabits
  • All of our fiber optic patch cables feature the high degree connectors
  • 100% optically tested to ensure high performance
  • Color: Aqua
  • Fiber class: OM4



Specifications

Specification Unit FC, SC, LC/Armored Cables ST, MU MT-RJ, MPO E2000
Single-mode Multi-mode Single-mode Multi-mode Single-mode Multi-mode Single-mode
PC UPC APC PC PC UPC PC PC UPC PC PC APC
Insertion loss dB ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.3
Return loss dB ≥45 ≥50 ≥60 ≥30 ≥45 ≥50 ≥30 ≥45 ≥50 ≥35 ≥55 ≥75
Wavelength nm 850,1310 850,1310 850,1310 850,1310
Interchangeability dB ≤0.2 ≤0.2 ≤0.2 ≤0.2
Vibration dB ≤0.2 ≤0.2 ≤0.2 ≤0.2
Operating temperature -40~75 -40~75 -40~75 -40~75
Storage temperature -45~85 -45~85 -45~85 -45~85
Cable diameter mm φ3.0,φ2.0,φ0.9 φ3.0,φ2.0,φ0.9 φ3.0,φ2.0,φ0.9 φ3.0,φ2.0,φ0.9




Fibermart Fiber Patch Cable Datasheet







Datasheet to Download

Customized Service :



● If you need any customized products or services, please write your request in Order Remarks, or send an email to [email protected]



Get Quote or Checkout Online :



● To request a Quote or Checkout to pay online, simply add items into your cart and select your preferred method.



Free Shipping & No Tariff :



● Online Order over US$200 is Free Shipping (Not included Heavy Items like Outdoor Cable, Outdoor Cabinet etc),

● For US customer, Fibermart covers all customs duty and fees - no additional tariff charges.



Shipping Time :



● FedEx : 2-4 business days
● UPS : 2-5 business days
● DHL : 2-6 business days
● Shipment by Sea : 20-25 business days



Payment Method :



● PayPal (Online)

● Credit / Debit Card (Online)

● ABA Routing (US Local)

● T/T Wire Transfer (International)



Returns & Warranty :



● 1-Year Warranty

● 60-Day Returns

● 60-Day Exchange

● Limited Lifetime Warranty.

   Read full Return & Refund Policy



Net Term & Credit :



● Fibermart accept Net 30 and Net 60 payment terms, Contact Us for Credit Account by submit a credit form.



Volume Discount :



● Fibermart offers discount prices for large-volume order, Contact Sales Team for more details.
