  • FC/APC to FC/APC Duplex Singlemode 9/125 Armored Patch Cable

FC/APC to FC/APC Duplex Singlemode 9/125 Armored Patch Cable

Product Item: #7860
(1 Customer Reviews)

Please Choose:

Price: Starting at: US$6.63
Add to Cart:
  • Description
  • Ordering Support
  • Other Remarks
  • Tags:

Armored Patch Cable FC/APC to FC/APC Duplex Singlemode 9/125

Armored patch cable can be deployed directly in different harsh environment, without additional tube for protection, save space, reduce construction cost, and make the maintenance more conveniently. This Duplex Singlemode Armored Standard fiber optic cable constructed with highest quality components for unmatched durability and reliability. With a Standard Boot on each end. This cable is appropriate for use in data centers and networks with 10GbE and 8G FC applications.
With OFNR (Riser)/OFNP(Plenum) and 3.0mm thickness, this Armored Fiber Optic cable is specifically designed for light to medium duty indoor/outdoor applications. Its rugged shell with steel and kevlar is 10 times stronger than regular Fiber Optic Cable and has a 40% higher rated range of operating temperature. Deploy this cable in environments where networking equipment undergo repeated abuse.

Fiber-Mart Singlemode 9/125 armored patch cable provide 1Gigabit data transfer speeds in high bandwidth application, up to 5 times faster than standard 9/125um fiber patch cable. With Fiber-Mart good development, we can offer more and more competitive price on a relatively higher-end heavy armored patch cables.

Warm Tips:The default fiber diameter for the cable is 3.0mm,if you'd like to customize other types as 0.9mm,2.0mm,please kindly enquiry us. (The diameter is refer to the thickness of the cable,the size is able to match the corresponding equipment port.)


  • Stainless steel tube & metal braid under outer LSZH jacket
  • Micro diameter stainless steel tube for protection
  • High resistance of tensile strength, pressure, rodent bite
  • Without damage by construction
  • Ensure transmission power and avoid additional attenuation
  • Prevent optic fiber from destroy by harsh environment
  • Prevent optic fiber from destroy by improper operation

  • Applications
  • FTTH, LAN, Test equipment, Military industry
  • CATV
  • Measuring equipments
  • Fiber optic communication system
  • Optical active component and equipment

    Item information
  • Fiber: Duplex Singlemode 9/125 Fiber Optic Cable
  • Connector: FC-FC Connectors at ends
  • Cable Jacket: Armored/Military Tactical
  • OFNR (Riser) Rated
  • Standard Boot on each end
  • Color: SM Blue

  • Structures

Each light armored patch cable is inserted in a protective flexible stainless steel tube as you see in the picture.

Custom OEM

Fiber-Mart offer customization solutions as below:

  • Any Fiber Type- 10G OM4 optical fiber, 10G OM3 optical fiber, Single-mode 9/125 optical fiber, OM1 Multimode 62.5/125 optical fiber and OM2 Multimode 50/125 optical fiber for choice.
  • Any connectors- FC, ST, LC, SC, MTRJ, E2000, MU etc connectors for choice.
  • Any lengths- 1m, 2m, 3m, 4m ...100m... no limits.
  • Label or Logo customs- we can print customer logo on fiber patch cable (as the following)


Connector Type FC to FC
Fiber Type Singlemode 9/125
Length 3m
Endface Type(nm) PC UPC APC
Insertion Loss(dB) ≤0.20 ≤0.20 ≤0.30
Repeatability(dB) ≤0.10
Exchangeability(dB) ≤0.20
Return Loss(dB) ≥45 ≥50 ≥60
Core Diameter 9.2µm ± 0.4µm @ 1310nm
Cladding Diameter 125µm ± 1µm
Outer Diameter 3.2mm ± 0.10mm
Max. Attenuation 0.5dB/km @ 1310nm
0.4dB/km @ 1550nm
Min Static Bend 10D
Min Dynamic Bend 15D
Tensile Load (long term) 200N
Tensile Load (short term) 400N
Crush (long term) 3000N/100mm
Operation Temperature(℃) -25℃~ +70℃
Storage Temperature(℃) -40℃~ +85℃
Durability(time) >1000 times
Industry Standard Telcordia GR-326-CORE
