MPO-16 to MPO-16 SingleMode 16 Strands Ribbon Flat MPO Fiber Cable

MPO-16 to MPO-16, 9/125um SingleMode, 16 Fibers MPO Ribbon Flat Fiber Cable, MPO-16 Fiber Jumper

MPO-16 is the high dense degree of optical fiber pre-connect system,which is generally use in three areas.

Fiber-Mart’s MPO fiber patch cables measure up IEC-61754-7 and TIA-604-5(FOCIS-5) standard, and applied to

• The data centra application with high dense degree environment
• The optical fiber to the building
• The internal connector application in fiber equipment such as Splitter, 40G /100G SFP and SFP+.

10G upgrade to 40G/100G data center.

MPO Connector Types

MPO Male with Pins	MPO Female without Pins
Two other clearly visible features are the noses and guide grooves (keys) on the top side.（Note:The Female and Male need to be used together.)

Pre-terminated MPO Technology-Polarity

The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.

Assembly Structure Illustration

MPO Trunk Fiber Patch Cables are terminated with MPO connector on both end.
1.The default diameter of the MPO cable is 3.0mm.
2.The diameter of branch cable could be choose as 0.9mm,2.0mm,please kindly contact us at [email protected] for other diameter standard.
3.We also support custom pulling eyes for the cable, welcome to contact me for details.

MTP/MPO Machinery & Testing Equipment

Parameter Reference

Note: Maximum Bandwidths of Different Multimode Fibers
OM1 – 62.5 um Core – 10GBit up to 33 meters, gigabit up to 300m
OM2 – 50 um Core – 10GBit up to 82 meters,gigabit up to 500m
OM3 – 50 um Core, Laser Optimized – 10GBit up to 300 meters,gigabit up to 1000m
OM4 – 50 um Core, Laser Optimized – 10GBit up to 550 meters,gigabit up to 1000m

Make To Order
