Optical Fault Tester FM-300

Description

The FM-300 fiber ranger is a high performance fiber fault locator which can be used to detect the fiber fault location and display the exact distance on the coloured LCD. The FM-300 is designed to be palm sized, lightweight, easy carry and simple operated which can be an ideal instrument for fiber installation, detection and maintenance.

Features

• 3-inch color LCD display large screen
• Chinese and English menu, easy to operate
• One-button testing, engineers can operate without any training
• Break point testing fast and accurate, range 0-80KM
• Four Ni-MH rechargeable batteries, continuous testing more than 5000 times
• USB communication interface
• Small, light weight, portable, easy to carry and maintenance.

Application

▪It is used for testing fiber breakpoint and fault, fast measurement: fiber break point with 100KM.
▪It be widely used in the MAN, WAN , CATV and other communication systems installation and maintenance
▪ With palm design, hi-technology chip, reliable performance, accurately detects fiber fault location.

Specifications

Item /Model No.	FM-300
Fiber Type	9/125 μm Single Mode
Wavelength	1550 ± 20nm
Emitter Type	LD
Connector Type	FC/PC (interchangeable SC,ST)
Pulse Width	Automatic mode10ns/20ns/40ns/80ns/160ns/320ns/640ns/1280ns/2560ns/5120ns/10240ns/20480ns
Max output power	90 mW
Max. Measurement Range	100 Km(Reflection event, >1dB)
Distance Accuracy	Reflection event	± (2 + 0.1% x Distance)
Non-Reflection event	± (100 + 0.5% x Distance)
Data Storage	260 measurements
Dead Zone	10 m (Reflection event )
Power Supply	AC/DC adaptor &. Rechargeable Batteries* 4
Battery Life	5,000 times measurement
Operating Temp.	-10 ~ +50ºC
Storage Temp.	-20 ~ +60ºC
Humidity	0 ~ 85% (non-condensing)
Communication Port	Mini USB
Weight	400 g
Dimension	19010555 mm
Max Event No.	13 reflective event +13 Non -reflective event

iberstore is specializing in supplying fiber optic components and network equipment, all the products are qualified because they have been 100% tested before delivery. A special discount will be provided if you need this brand new optical fault tester FM-300 at a large quantity.
