Simplex 9/125 Single-mode E2000 Pigtail



Fiber pigtail cables provide a fast way to make factory terminations in the field. Factory terminated pigtails can easily be fusion or mechanically spliced to an existing fiber line.
Fiber-Mart.COM provide wide degree flexibility on fiber pigtails, including single-mode, multimode and 10G 50/125um OM3 types, simplex fiber, 4 fibers, 6 fibers, 8 fibers, 12 fibers, 24 fibers, 48 fibers and so on. These fiber pigtails can be with fan-out kits and full compliant to Telcordia, EIA/TIA and IEC standards.



Features

  • Low insertion loss and back reflection loss
  • Good exchangeability
  • Good Durability
  • High temperature stability
  • Compliant to IEC, TIA/EIA, NTT and JIS specifications

Applications

  • FTTx, LAN, PON
  • Optical CATV
  • Local ring net
  • Optical fiber communication system
  • Optical fiber test equipment
  • Optical fiber sensor



Specification

Parameter Specification
Connector E2000
Fiber Simplex
Mode Type Singlemode 9/125
Polishing UPC
Insert Loss ≤ 0.2 dB
Return Loss PC/UPC > 35dB APC > 60dB
Temperature Range -40 ~ +55 ° C
Cable Diameter 0.9mm /2.0mm /3.0mm
(Price is same for the 3 diameters. You can specify your requirements in your order comments.)


Custom Information

Fiber-Mart offers custom-made pigtails with a wide variety of options:
a. “Unjacketed” fiber pigtails usually installed inside ODF unit.
b. Multi-Strand fiber pigtails without a jacket are ideal for fusion splicing.
c. Multi-Strand fiber pigtails with fan-out are designed for patch panels or cable ducts where space-saving is required.
d. 2, 4, 6, 8, 12, 24 and 48 Strand fiber counts available.
Note :All pigtails can be customized in any fiber type, length, connectors and fiber counts for your requirement.
