1x128 PLC Fiber Splitter Singlemode ABS Box Package

Product Item: #17356

(1 Customer Reviews)

P/N: PLC-A-1X128

Starting at: US$295.00

Please Choose:

Fiber Type:

Fiber Length:

Connectors:

Customized Details:

Order Today, Ship before 06/11/2026, from U.S. or Hong Kong

Description
Datasheet
Tags
FAQ

FiberMart 1x128 Fiber PLC Splitter, ABS Box Package, 1x128 PLC Splitter, 1x128 Fiber Splitter can distribute or combine 1 optical signal into 128 outputs fibers.

PLC Splitter is based on planar lightwave circuit technology.

The 1x128 PLC Splitter, with 1.5m pigtail length G.657A Fiber, 0.9mm, 2.0mm, 3.0mm input and output fiber for choice, and FC, SC, ST & LC connectors for choice, features high reliability, small size, wide operating wavelength range and good channel-to-channel uniformity and provide a cost effective and space saving product suitable to the ever changing networking requirements, and now is widely used in PON networks to realize optical signal power splitting.

ABS Box PLC Splitter Features

Low insertion loss
Low Polarization Dependent Loss
Good channel-to-channel uniformity
Wide Operating Wavelength: 1260~1650nm
High Reliability and Stability
Telcordia GR-1209-CORE-2001 Compliant
Telcordia GR-1221-CORE-1999 Compliant
Fiber input: 0.9 mm, 2.0mm or 3.0mm fiber for choice
Fiber output: 0.9 mm, 2.0mm or 3.0mm fiber for choice

ABS Box PLC Splitter Applications

Fiber to the point (FTTX)
Fiber to the home (FTTH)
Passive optical networks(PON, GEPON)
Local area networks (LAN)
Cable television (CATV)
Telecommunication Networks

Mechanical Drawing

1x32, 1x64, 1x128, 2x32, 2x64, 2x128: 140*115*18 mm

V.S FBT Coupler, the advantages of PLC are as follows

The loss to different wavelength transmission is not sensitive, so it can meet the transmission requirements of different wavelength
High spectral uniformity, can splitter the signals on average
Compact structure, small volume
The cost advantage is very obvious on many splitter channels

Order Information

Fiber-Mart provides a whole series of 1xN and 2xN splitters that are tailored for specific applications:
a.1x2, 1x4, 1x8, 1x16,1x32, 1x64, 1x128, 2x2, 2x4, 2x8, 2x16, 2x32,2x64, 2x128 Versions of splitters are available.
b. SC/UPC, FC/UPC, LC/UPC, SC/APC, FC/APC, LC/APC connectors or no connectors can be selected as you like
c. 0.9, 2.0, 3.0mm for input & output fiber type.
d. The length of pigtail can be also customized; usually we will provide you 1.5m, welcome to contact us for more details.

Fiber-Mart provides a various of 1xN and 2xN PLC ABS box splitters. The ABS Box PLC Splitter with its compact structure and small volume, are very convenient for use and can be installed in many places, such as: 19 inch racks, cross connect cabinet and some other devices. For more information about 1x2 Fiber PLC Splitter SMF-28e fiber with Plastic ABS Box Package, please contact us at [email protected].

Our Factory

Parameter	Port Configuration
Parameter		1X2	1X4	1X8	1X16	1X32	1X64
Fiber Type	G.657A
Operating Wavelength(nm)	1260～1650
Insertion Loss(dB)	Typical	3.9	7	10.2	13.2	16.2	19.7
Insertion Loss(dB)	Max	4.2	7.4	10.7	13.7	17.1	21.2
Loss Uniformity (dB)	Max	0.4	0.6	0.8	1.2	1.5	2.5
Return Loss (dB)	Min	50	50	50	50	50	50
PDL (dB)	Max	0.2	0.2	0.3	0.3	0.3	0.4
Directivity (dB)	Min	55	55	55	55	55	55
Wavelength Dependent Loss(dB)	Max	0.3	0.3	0.3	0.5	0.5	0.8
Temperature Dependent Loss (-40~+85°C)	Max	0.5	0.5	0.5	0.8	0.8	1
Operating Temperature (°C)	-40~+85
Storage Temperature (°C)	-40~+85
