22dBm Output 1550nm Polarization Maintaining EDFA Fiber Optic Amplifier

Polarization Maintaining EDFA Fiber Optic Amplifier 22dBm Output 1550nm

Description

This optical amplifier is high stability output Polarization Maintaining (PM) EDFA. The key components of the product are high reliability PUMP laser. A unique APC (Automatic Power Control) and ATC (Automatic Temperature Control) circuit insures the high stability and reliability output power,the unique optical circuit design ensures the excellent optical performance. The high stability and high precision MPU system to ensure the control, adjustment and monitor are intelligent and easy.


Features

• Output stability <0.1dB
• Single mode PM output
• High stability and reliability: MTBF＞100000 hours
• Perfect status monitoring interface: RS-485 and RS-232
• High precision AGC/APC circuit: power control accuracy typ ±0.05dB
• Intelligent temperature control system: power consumption and hot radiation reduce 30％ than common products
• Compact size and circuit
• OEM is optional
• Compatible with Bellcore GR-1312-CORE

Applications

1. PM fiber sensor
2. Coherent detection
3. Free space optical communication
4. Research and Design area

Mechanical Dimension

Module dimension: 150×125×19 (mm)

Order Information

Optical Characteristics

Electric Characteristics

※Actual consumption depend on the output power and environment temperature

Environmental Characteristics

Note:Non-condensing
