5 channels 1RU Rack Mount Simplex CWDM OADM East-and-West

5 channels CWDM OADM East-and-West 1RU Rack Mount Simplex

Simplex CWDM OADM for East-and-West Traffic

The Simplex CWDM/AD modules add (multiplex) and drop (demultiplex) selected wavelengths over single fiber Simplex CWDM MUX & DEMUX link for East-and-West Traffic.

Fiber-Mart CWDM OADM ( CWDM/AD) modules are Course Wave Division Multiplexing (CWDM) Optical Add and Drop Multiplexers (OADM). "Add" and "drop" here refer to the capability of the device to add one or more new wavelength channels to an existing multi-wavelength WDM signal, and to drop (remove) one or more channels, passing those signals to another network path.

The CWDM/AD is a passive optical add/drop multiplexer designed for point-to-point, ring, or bus configurations' applications that provides the ideal solution for the increasing bandwidth demand on enterprise and metro access networks and delivers dramatic cost savings to network equipment manufacturers, enabling them to develop metro access systems that are lower in cost, easier to provision and simpler to operate.

Added/dropped channels are interfaced to any of Fiber-Mart CWDM transceivers on the equipment side, and we also provide optional port configurations such as: Express Port, Monitor Port, 1310nm passband port and 1550nm port for these multiplexers according to customer choice.

Front Panel Details

NOTE:

• Actual layout depends on the chosen connector type as well as other factors. However, the principal scheme stays the same
• We also provide optional port configurations such as Monitor Port for these multiplexers according to customer choice, need more details, please contact at [email protected]

Item Details

• 5 channels CWDM OADM
• 2 x Common ports for West and East traffic: Simplex Connector
• All Add/Drop Channels for West and East traffic: Duplex Connector; Channel separation 20nm from 1270nm to 1610nm
• 1U 19 inch Rack Mount Housing
• OADM complement to the express CWDM product line
• Compliant to ITU-T G.657A1 CWDM standard
• Protocol and rate transparent for applications up to 10Gbp
• Low-cost transceivers applicable, existing equipment can still be used
• It is equipped with configuration ports like Monitor, Express port according to customer choice (see options)
• Front panel is equipped with adapters according to customer choice (see options)
• ISO 9001 manufacturing facility

Mechanical Details for Housing

Please note that the drawings shown here only show the dimensions and do not the specific configuration of the module.
