3.5 inch CCTV Security Tester STest-893 with PTZ Controller and Power Supply



Introduction

The CCTV testerPRO STest-893 is developed for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, testing video level, controlling PTZ, scanning PTZ address, generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down.



Features

3.5"TFT-LCD, 960 (H) × 240(V) resolution
DC12V power output
Audio input
Adjustable brightness, contrast, color of LCD
Video Level testing, video signals measured in IRE or mV
Automatically identify and adapt the video mode of NTSC and PAL
Colorbar Video signal generator, transmit/receive colorful images
Support more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc
PPTZ address scanning, search up the ID of PTZ camera.
Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.
Support RS232 and RS485 interface, the rate 150-19200bps
Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset.
Lithium Ion Polymer Batteries (3.7V DC3000mAh), more reliable, and work 15 hours
Easy for use that the train is almost unnecessary



Application

CCTV system installation and maintenance
Dome camera and All in one camera testing
The CCTV transmitting channel testing
PTZ controller



Family Comparison

STest-890 2.8"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL color bar generator, PTZ controller, UTP cable tester, PTZ data analyst, PTZ address scanning, Lithium Ion Polymer Battery support 11 hours working time.
STest-891 2.8"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL color bar generator, PTZ controller, UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Lithium Ion Polymer Battery support 15 hours working time.
STest-893 3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL colorbar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Lithium Ion Polymer Battery support 12 hours working time.
Stest-894 3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL colorbar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Digital multimeter, Lithium Ion Polymer Battery support 12 hours working time.
STest-895 3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL colorbar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Digital multimeter, Optical power meter, Lithium Ion Polymer Battery support 12 hours working time.
STest-896 3.5"TFT-LCD, LCD Brightness/Contrast/Color Saturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL color bar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Optical power meter, Lithium Ion Polymer Battery support 12
hours working time.



Model CCTV Security Tester 893
Video Test
Signal mode NTSC/PAL (Auto adapt)
Display 3.5 inch digital TFT-LCD ,960 x 240 resolution
LCD adjustment Brightness, Contrast, Saturation adjustable
Video IN/OUT 1 channel BNC Input & 1 channel Output
Video Output Mode 1.0 Vp-p
Video Level test Video signals measured in IRE or mV
Power Output
Power Output DC12V, 1A
Audio Test
Audio input 1 channel Audio input
PTZ controller
Communication RS232, RS422 simplex and RS485
PTZ Protocol Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.
Baud Rate 150,300,600,1200,2400,4800,9600,19200bps
Video Signal Generation
Color bar generation Output channel colorbar video signal for testing monitor or video cable
UTP CABLE TEST
UTP cable test Test UTP cable connection status and display in the screen. Read the number of the test box.
RS485 data analyst
Data Monitor Captures and analyzes the command data from controlling device
POWER
Power Adapter DC5V, 2A
Battery Built-in 3.7V Lithium polymer battery ,3000mAh
Rechargeable After charging 4.5 hours, working time lasts 12 hours
Low Consumption Energy saving technology
General
Working Temperature -10°C~+50°C
Working Humidity 30%-90%
Dimension/Weight 175mmx94mmx40mm/360g




Datasheet to Download
