HP780 Fiber Patch Cable Singlemode 630-HP 1M FC APC

Product Item: #18011
(2 Customer Reviews)
P/N: SM780-HP-FCA-X
Starting at: US$52.00

Please Choose:







Order Today, Ship before 06/11/2026, from U.S. or Hong Kong
  • Description
  • Datasheet
  • Tags
  • FAQ

780nm SM Fiber Patch Cord FC APC to FC APC SM 780-HP Fiber Patch Cable



780nm optical fiber patch cords are widely used in polarization sensitive fiber optical systems for transmission of light that requires the 780nm wavelength state to be maintained.


FiberMART provides 780-HP patch cords at two different wavelengths, including 630nm, 530nm. Our 780-HP patch cord features high extinction ratio, low insertion loss, high return loss and long term reliability.

This price on the website is for 1M length,please feel free to enquiry us for the other length standard



Festures

FC-FC Connectors
Typical Return Loss: UPC type: ≥50 dB; APC type: ≥55 dB
Ceramic 8° Angled Ferrules (APC)
Ø0.9/2.0/3.0mm Protective Outer Jacket
Low insertion loss
Excellent repeatability and changeability
Each patch cable is manufactured and tested to ensure its quality to meet the highest standard.



Applications

Optical fiber communication systems

Optical component test and manufacturing

Optical sensor systems



Specifications

Specification Unit FC, SC, LC/Armored Cables ST, MU MT-RJ, MPO E2000
Single-mode Multi-mode Single-mode Multi-mode Single-mode Multi-mode Single-mode
PC UPC APC PC PC UPC PC PC UPC PC PC APC
Insertion loss dB ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.3
Return loss dB ≥45 ≥50 ≥60 ≥30 ≥45 ≥50 ≥30 ≥45 ≥50 ≥35 ≥55 ≥75
Wavelength nm 1310,1550 1310,1550 1310,1550 1310,1550
Interchangeability dB ≤0.2 ≤0.2 ≤0.2 ≤0.2
Vibration dB ≤0.2 ≤0.2 ≤0.2 ≤0.2
Operating temperature ℃ -40~75 -40~75 -40~75 -40~75
Storage temperature ℃ -45~85 -45~85 -45~85 -45~85
Cable diameter mm φ3.0,φ2.0,φ0.9 φ3.0,φ2.0,φ0.9 φ3.0,φ2.0,φ0.9 φ3.0,φ2.0,φ0.9
