LC to ST Duplex OM2 MultiMode 7.0mm LSZH FTTA Outdoor Fiber Patch Cable

Press Esc key to close this popup
  • LC to ST Duplex OM2 MultiMode 7.0mm LSZH FTTA Outdoor Fiber Patch Cable
  • LC to ST Duplex OM2 MultiMode 7.0mm LSZH FTTA Outdoor Fiber Patch Cable
  • LC to ST Duplex OM2 MultiMode 7.0mm LSZH FTTA Outdoor Fiber Patch Cable

LC to ST Duplex OM2 MultiMode 7.0mm LSZH FTTA Outdoor Fiber Patch Cable

Product Item: #17621
P/N: FTTA-OM2-LCU-STU-DX-LSZH
Starting at: US$12.00

Please Choose:






Order Today, Ship before 06/11/2026, from U.S. or Hong Kong
  • Description
  • Datasheet
  • Tags
  • FAQ

Fiber To The Antenna (FTTA) Patch Cable Armored LSZH for Outdoor Applications, LC to ST OM2 Multimode FTTA Armored fiber patch cable



FTTA fiber patch cable is designed for high reliability in heavy industrial and harsh environment applications, including fiber to the antenna solution. FTTA Fiber Cable.




Consisting of Corning fiber cable and LC UPC duplex connectors, the cable features superior crush resistance and a high degree of flexibility with the armored tube. Furthermore, the cable features a flame retardant LSZH jacket which is UV stabilized and highly resistant to chemicals commonly found in industrial environments, also suitable for both indoor and outdoor industrial installations.

Product Specifications
Connector Type LC to ST Polish Type UPC to UPC
Fiber Mode OM2 Wavelength 850/1300nm
Insertion Loss ≤0.3dB Return Loss ≥50dB
Fiber Grade Corning G.657.A1 Min. Bend Radius (Dynamic/Static) 20/10D
Attenuation at 1310 nm 0.36 dB/km Attenuation at 1550 nm 0.22 dB/km
Fiber Count Duplex Cable Jacket Low Smoke Zero Halogen (LSZH)
Cable Diameter (Outer/Inner) 7.0/2.0mm Armored Breakout Length (End A/B) 0.03/0.34m
Tensile Strength (Long Term/Short Term) 400/200N Crush Resistance (Long Term/Short Term) 2200/1100N
Operating Temperature -20~70°C Storage Temperature -40~80°C



Product Spotlight

Superior Flexibility

Corning G.657.A1 bend insensitive fiber

Excellent flexibility for remote traction

Certification & Standards

IEC 61754 series compliant

Qualified to Telcordia GR-326-Core

ISO 9001, Reach, RoHS compliant

Test Assured Program

Insertion loss and return loss testing

End-face inspection

3D interferometer test




Product Highlights

Designed for Outdoor Base Station Construction

This type of specialized fiber patch cable is designed for harsh environment application such as high performance fiber-to-the antenna (FTTA) cabling for current 4G/LTE and 5G network and base station construction connecting AAU and RRU, also suitable for wireless horizontal and vertical cabling in indoor/outdoor environment.

FTTA Patch Cables  Designed for Outdoor Base Station Construction

Corning G.657.A1 Fiber

Corning BIF cable can be stapled and bent around corners without sacrificing performance.

FTTA Patch Cables  Corning G.657.A1 Fiber

Stainless Armored Tube

Hard spiral armored tube makes the FTTA Fiber Cable more stable and higher tensile strength.

Strength Members

Two strength members firm the cable and make it more convenient for pulling when installing.

FTTA Patch Cables  Strength Members
FTTA Patch Cables LSZH Rated Outer Jacket
LSZH Rated Outer Jacket

Jacketed with compounds that emit limited smoke and no halogen when exposed to high heat sources.


Cable Assembly Structure Illustraion
FTTA Patch Cables  Cable Assembly Structure Illustraion









Customized Service :



● If you need any customized products or services, please write your request in Order Remarks, or send an email to [email protected]



Get Quote or Checkout Online :



● To request a Quote or Checkout to pay online, simply add items into your cart and select your preferred method.



Free Shipping & No Tariff :



● Online Order over US$200 is Free Shipping (Not included Heavy Items like Outdoor Cable, Outdoor Cabinet etc),

● For US customer, Fibermart covers all customs duty and fees - no additional tariff charges.



Shipping Time :



● FedEx : 2-4 business days
● UPS : 2-5 business days
● DHL : 2-6 business days
● Shipment by Sea : 20-25 business days



Payment Method :



● PayPal (Online)

● Credit / Debit Card (Online)

● ABA Routing (US Local)

● T/T Wire Transfer (International)



Returns & Warranty :



● 1-Year Warranty

● 60-Day Returns

● 60-Day Exchange

● Limited Lifetime Warranty.

   Read full Return & Refund Policy



Net Term & Credit :



● Fibermart accept Net 30 and Net 60 payment terms, Contact Us for Credit Account by submit a credit form.



Volume Discount :



● Fibermart offers discount prices for large-volume order, Contact Sales Team for more details.



Customer Reviews


by APOLONIO IGMEN
Date Added: 01/30/2024
High quality and fair price,we found the cable is stable to connect and its loss is low in process of using it, good cable.

Rating: 5 of 5 Stars [5 of 5 Stars]
LC to ST Duplex OM2 MultiMode 7.0mm LSZH FTTA Outdoor Fiber Patch Cable LC to ST Duplex OM2 MultiMode 7.0mm LSZH FTTA Outdoor Fiber Patch Cable



Please tell us what you think and share your opinions with others. Be sure to focus your comments on the product.
