Manual-Align Fiber Array to Waveguide Alignment Stages for PLC Fiber Splitter Manufacturing

Manual Align Optical Waveguide Alignment Machine for Fiber Chip Coupling Manufacuturing, Optical Coupling system of Optical Chip and Fiber Array, Optical Fiber Align System & optical waveguide alignment and packaging

Low-cost, Compact, High Precision and Maneuverable Manual-Alignment Machine for PLC Splitter Manufacuring and Alignment of PLC Fiber Chip and Fiber Array Pigtailing

The Sunma instrument company develops a new generation of manual and auto aligner for planar lightwavecircuit(PLC)manufacturing. This product line features cost effective, high precision motion control capability with a compact mechanical design. Optical Alignment Machine
High quality components are used to assemble the system to guarantee high precision and repetitive motion applications.OEM customized manual, semi-auto and fully automatic system according to customer’s applications.
We provide 2-day Free training, Installation& Calibration, all for Free.

Features:

• High Stability Stainless Steel Ultra-Precision linear stage
• High Repeatability Stainless Steel fixtures and jigs
• High resolution motion platform and micrometer for high precision and repeatability waveguide alignment
• Compact and highly maneuverable design
• Modular design, seamless upgrade to piezo-electric and motor-driven semi-auto alignment system

Applications:

• Silicon waveguide alignment/coupling
• 1xN Splitter
• 2xN splitter
• Arrayed waveguide grating
• Collimator
• Special/customized optical fiber and other related optical waveguide alignment

System confguration:

Specifications:
