2.5mm OD Multi-mode Ceramic Ferrule for SC Fiber Connector 1.0um

Press Esc key to close this popup
  • 2.5mm OD Multi-mode Ceramic Ferrule for SC Fiber Connector 1.0um
  • 2.5mm OD Multi-mode Ceramic Ferrule for SC Fiber Connector 1.0um
  • 2.5mm OD Multi-mode Ceramic Ferrule for SC Fiber Connector 1.0um
  • 2.5mm OD Multi-mode Ceramic Ferrule for SC Fiber Connector 1.0um

2.5mm OD Multi-mode Ceramic Ferrule for SC Fiber Connector 1.0um

Product Item: #2268
(1 Customer Reviews)
P/N: MM-SC-10-FM
US$0.52
  • Min:  100



    • Order Today, Ship before 04/23/2024, from U.S. or HK
    • Description
    • Datasheet
    • Tags

    2.5mm OD Multi-mode Ceramic Ferrule for SC Fiber Connector 4.0um



    Specification:

    Outer diameter: 2.4990±0.001mm
    Inner diameter: (0.126～0.129）mm
    Concentricity: 4.0μm
    Insertion loss:≤0.2dB
    return loss:≥50dB
    length:（10.50±0.01）mm



    Features:

    Good compatibility
    Accurate mechanical dimensions
    Good reliability and stability
    Compliant with RoHS, Bellcore, IEC



    Application:

    Telecommunication
    CATV
    LAN (including FTTx)
    Data network





    Datasheet to Download
