FTTH Fiber Optic Splice Protection Sleeve-Single Fiber 1.0x60mm 50pcs/pkg

Press Esc key to close this popup
  • FTTH Fiber Optic Splice Protection Sleeve-Single Fiber 1.0x60mm 50pcs/pkg

FTTH Fiber Optic Splice Protection Sleeve-Single Fiber 1.0x60mm 50pcs/pkg

Product Item: #9037
P/N: FM-1060F
US$3.00



Order Today, Ship before 04/03/2024, from U.S. or HK
  • Description
  • Datasheet
  • Tags

FTTH Fiber Optic Splice Protection Sleeve-Single Fiber 1.0x60mm 50pcs/pkg



Description

This products is made up of cross linked polyolefin heat-shrinkable tubes,hote melt tubes and Stainless steel needle. It is specifically designed for the protection of fiber optical closure



Features

  • Protect connection point,improve the mechanical strength,it is most reliable way to protect the fusion.
  • Esay to operate,reducing the risk of fiber damage during installation
  • Transparent tube,it is easy to see the status of fiber optical closure
  • Min.shrinks temperatuer:120℃,shrink very fast and very easy to installation
  • Work temperature high (-55°C~100°C), widely used
  • Sealing structure let closure have good resistance to temperature and humidity performance.



Ordering Information

Type Length of tube Hot-melt tube Steel needle
After recover Length(mm) Inside dia Length(mm) Inside dia Length(mm)
FM-1045 5.8 45 3.6 45 1 40
FM-1060 5.8 60 3.6 60 1 55
FM-1040 5.8 40 3.6 40 1 35



Quantity per package: 50pcs/pkg

Note: We also provide this kind of protection sleeves with 1000pcs/pkg and good price.

Fiber-Mart can provide both domestic and foreign products, and for this kind of fusion splicer assemblies that used in the fiber optic fusion splicing, most of them can be used together with the foreign famous brand fusion splicer. If you want this FTTH Cable Fiber Optic Splice Protection Sleeve FM-1060 in a large quantity, welcome to contact us at service [email protected], we will provide you the best price.


Item Test method Performance
Temperature IEC216 -55°C~100°C
Tensile strength ASTM D 2671 18MPa
Elongation at break ASTM D 2671 700%
Density ISO R1183D 0.94g/cm3
Dielectric strength IEC243 25kV/mm
Volume resistance IEC243 1015Ω
Dielectric constant IEC243 2.5
Longitudinal change ASTM D 2671 ±5%
Eccentricity ASTM D 2671 105


Datasheet to Download
