ST-8105 Multi channel High-speed Optical Power Meter

SUNMA ST-8105 Multi channel High speed Optical Power Meter

ST-8105 multi channel desktop optical power meter is a high precision and wide range optical power detection device developed by SUNMAFIBER. Intelligent microprocessor control, with automatic range switching, optical detector pin in the whole range of the 7 segments of the linearization processing, eliminating the pin at the same wavelengths and power, response error caused by the nonlinearity of optical power, greatly provided high accuracy and reliability of the testing equipment.

In addition to the traditional optical power meter function, ST-8105 also uses a new data acquisition technology, making the power meter has a greater signal to noise ratio, a greater dynamic range. In the small signal, the internal circuit uses the small resistance to add the shield technology, causes the ST-8105 to have the higher sensitivity, the power display value -75 ~ +3dBm.

ST-8105 also provides RS232 communication function, upper computer software using ST-8105 incidental to the user provides a friendly and convenient interface, to meet the power monitoring, to achieve unattended, paperless recording, automatic data storage requirements.

ST-8105 correction method is simple and convenient, as long as there is a standard optical power meter can be calibrated to its accurate unabated, calibration is simple and easy to operate.

ST-8105 is equipped with 1260/1310/1490/1550/1625/1640 six wavelength switching points, which can be used for direct measurement of optical power. Optical fiber communication systems research, development and production, and construction, maintenance and other departments necessary basic testing equipment, and the performance test of optical device output power, optical fiber and optical cable and optical passive devices ideal measurement tools.

Features:

The whole appearance is compact, beautiful, stable, reliable, and easy to operate.
High sensitivity and high display resolution.
Large dynamic range, optional range.
The new data acquisition technology, with more large noise ratio and dynamic range.
The RS232 communication function, to realize unattended power monitoring, automatic data storage.

Application:

- The production and research of optical devices
- Fiber optic sensing research
- optical fiber CATV project
- Optical fiber communication engineering
- other optical fiber engineering

Specification

Model ST-8105
Calibration wavelength (nm) 126013101490155016251640
Probe type InGaAs
Interface type PC/FC
Measurement range (dBm) -75 ~ +3
Display unit dBm
Communication interface RS232
Working temperature (c) -10 ~ +40
Storage temperature (c) -25 ~ +70
Working power supply (V) AC90 ~ 260 (50Hz)
Weight (kg) 7
Appearance size (mm) 450*425*145

Packing:

1 ST-8105 machine 1 sets
2 manual 1
3 serial communication line RS232 1
4 power cord 1
5 fuse 2
6 CD CD 1
7 clean cotton swab 1 Pack
