Athermal AWG, DWDM Demux, 48 channels, 1RU Rack Mount, Simplex Uni-directional

Product Item: #16700
P/N: 48DS-1RU-A5-FM-DWDM
US$985.00

Please Choose:



Special Port











Order Today, Ship before 07/12/2022, from U.S. or HK
  • Description
  • Datasheet
  • FAQ
  • Tags

Simplex DWDM DEMUX



Demultiplexer (DEMUX) work with multiplexer (MUX) on the other side for single directional data transmission over one fiber.

DWDM Mux/Demux modules are part of a series of high performance products based on silica-on-silicon planar technology. The AWG chips Fiber-MART.Com used for DWDM Mux/Demux are targeted for Long-Haul, Metro and access applications, where outstanding optical performance and low cost are paramount.
Athermal Arrayed Waveguide Grating (AAWG) DWDM Modules features of athermal packaging design require no electrical power, software or temperature control.
Thermal Arrayed Waveguide Grating (TAWG) DWDM Modules are designed for use within the C-band release of DWDM system. To decrease the power dissipation of the devices in different environmental conditions, the AWG package is special designed with selection of reliable thermal plastic with low thermal conduction, and the AWG operating temperature is controlled by using foil resist heater or Peltier TEC with thermistor temperature sensor.
The channel spacing for DWDM is 1.6/0.8/0.4 nm (200GHz/100 GHz/50 GHz grid). This small channel spacing allows to transmit simultaneously much more information.


Front Panel Details


Note: Actual layout depends on the chosen connector type as well as other factors. However, the principal scheme stays the same.


Item Details

  • 64 channels DWDM DEMUX in one 1U Rack
  • The channel spacing for DWDM is 0.4 nm (50 GHz grid)
  • Com port is simplex
  • 1U 19inch Rack Mount Housing
  • Protocol transparent (10 Mbps to 100 Gbps)
  • Distance: Up to 80 km depending on power budget of user equipment
  • Low insertion loss
  • Excellent channel isolation
  • Epoxy-free optical path
  • Compliant to G.657A1 standard.
  • ISO 9001 manufacturing facility

Mechanical Details for Housing




Note: Please, note that the drawings shown here only show the dimensions and do not the specific configuration of the module.




If any option which is not indicate in your Ordering, please write your option or request in your Order Remarks, or send email to [email protected].



You can place order and checkout online at Fiber-MART.COM, you can send us a Purchase Order for offline purchase, or request a Proforma Invoice to make everything clear!



Shipping Time


FedEx IP: Within 1-4 business days
FedEx IE: Within 4-6 business days
DHL: Within 2-6 business days
EMS: Within 4-15 business days
UPS: Within 1-3 business days
Hong Kong Post Airmail: Within 10-30 business days


Payment:


Paypal or Credit/debit card
Wire Transfer, West Union


Returns:


Satisfactory return or item exchange


Guarantee:


Money back guarantee


Warranty:


Limited Warranty


Volume pricing:


If you need large order volume, please apply for a business account or contact us to enjoy preferential policies.
