SC/UPC Fiber Optic Attenuator Male to Female Singlemode, Fixed Type

As optical passive devices,Fiber-MART attenuators are mainly used in fiber optic to debug optical power performance & optical instrument calibration correction & fiber signal attenuation to ensure the optical power in a stable and desired level in the link without any changes on its original transmission wave.

Fiber Connector	SC/UPC	Ferrule Type	Zirconia Ceramic
Connector Gender	Fixed Male to Female	Transfer Mode	Singlemode
Attenuation	1~25dB	Operating Wavelength(nm)	1260~1620(SM)
Attenuation Accuracy	±0.5dB	Return Loss	≥45dB
Polarization Dependent Loss	≤0.2dB	Max Optical Input Power	200mW
Humidity	95%RH	Operating Temp Range	-40~80°C
Storage Temp Range	-40~85°C

Highlights

Fixed SC/UPC Singlemode Fiber Optic Attenuator, 1dB

Precise attenuation values
Low PDL & insertion loss
Precisional reflection polishing

1. Flexiable case for easy portability

Accurate size armed with elegant dust cap, better ensure the handy installation and protection from out-service.

2. Durable metal shell for permanent protection

Shaped with metal material, our attenuators perfectly protect the core insert from external damage.

3. Elaborately designed packing for no-damage delivery

Delicate packaging, convenient for using and well-protected in transit to ensure no-damage delivery.

Attenuator Application

Optical attenuator is a passive device used to reduce the power level of an optical signal. It is generally used in single-mode long-haul applications to prevent optical overload at the receiver. Optical attenuator is widely used in CWDM&DWDM, CATV systems, data center networks, test equipment and other high power applications.
