100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 10km Optical Transceiver Cisco QSFP-100G-LR4-D

Product Item: #16791
(1 Customer Reviews)
P/N: QSFP28-LR4-100GFM
US$779.00

Please Choose:






Order Today, Ship before 06/16/2026, from U.S. or Hong Kong
  • Description
  • Datasheet
  • Tags
  • FAQ

Cisco QSFP-100G-LR4-D Compatible 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate Optical Transceiver Module for Telecom (SMF, 1310nm, 10km, LC, DOM)



Cisco Compatible QSFP-100G-LR4-D Vendor Name Fibermart
Form Factor QSFP28 Data Rate Dual Rate 103.1Gbps and 112Gbps
Wavelength 1310nm* Max Cable Distance 10km@SMF
Connector LC duplex Media SMF
Transmitter Type 4 x LAN WDM DML TOSA Receiver Type 4 x PIN ROSA
DDM/DOM Supported Commercial Temperature Range 0 to 70°C (32 to 158°F)
TX Power(100G) -4.3~4.5dBm Receiver Sensitivity(100G) <-8.6dBm
TX Power(112G) -0.6~4dBm Receiver Sensitivity(112G) <-8.4dBm
Power Consumption 3.5W Extinction Ratio 4dB
Modulation Format NRZ CDR TX and RX
Transmit and Dispersion Penalty 2.2dB Powerbudget 6.3dB
Packaging Technology BOX Packaging FEC Function** Supported
Protocols 100G Ethernet, 25G Ethernet, OTN OTU4 4I1-9D1F Application 100GBASE Ethernet, Telecom, 5G Network Mid/Backhaul

Please Note:
* 1310nm wavelength range include L0 1295.56nm(1294.53-1296.59nm), L1 1300.05nm(1299.02-1301.09nm), L2 1304.58nm(1303.54-1305.63nm), L3 1309.14nm(1308.09-1310.09nm)
** It does not employ the use of FEC, complied with the IEEE 100GBASE-LR4 specification.


Product Tree

Direct Connection for 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Transceivers for Telecom and 5G wireless Network



Datasheet

Part Number

Distance

Fibers

Port

Datasheet

QSFP28-SR4-100GFM

100m

 MMF MTP/MPO-12

QSFP28-PIR4-100GFM

500m

 SMF MTP/MPO-12

QSFP28-IR4-100GFM

2km

 SMF LC

QSFP28-LR4-100GFM

10km

 SMF LC

QSFP28-BLR4-100GFM

10km

 SMF LC

QSFP28-ER4-100GFM

40km

 SMF LC


Quality Certifications



Please Note: Installing a third party transceiver does not void your network equipment warranty. Network equipment manufacturers all have guidelines stating that warranty support on their products will not be affected.



Test Bed

Cisco Catalyst C9500-24Y4C


Platform Support

Cisco QSFP-100G-LR4-D is supported on a wide range of Cisco equipment.



Cisco Nexus N9K-C92160YC-X Cisco Nexus 3000 Series N3K-C3232C Cisco Nexus 9000 Series (Fixed 9200) N9K-C92160YC-X Cisco Nexus 9000 Series (Modular 9500) N9K-X9432C-S
Cisco ONS Transport Platform NCS-1002-K9Cisco Catalyst C9500-24Y4CCisco Nexus 9300-EX Series 93180YC-EXCisco NCS-5501




Part Number

Distance

Fibers

Port

Datasheet

QSFP28-SR4-100GFM

100m

 MMF MTP/MPO-12

QSFP28-PIR4-100GFM

500m

 SMF MTP/MPO-12

QSFP28-IR4-100GFM

2km

 SMF LC

QSFP28-LR4-100GFM

10km

 SMF LC

QSFP28-BLR4-100GFM

10km

 SMF LC

QSFP28-ER4-100GFM

40km

 SMF LC



Datasheet to Download

Add your Tags

112GBASE-OTU4 | 100GBASE-LR4 | Dual Rate Transceiver |

Customized Service :



● If you need any customized products or services, please write your request in Order Remarks, or send an email to [email protected].



Get Quote or Checkout Online :



● To request a Quote or Checkout to pay online, simply add items into your cart and select your preferred method.



Free Shipping & No Tariff :



● Online Order over US$200 is Free Shipping (Not included Heavy Items like Outdoor Cable, Outdoor Cabinet etc),

● For US customer, Fibermart covers all customs duty and fees - no additional tariff charges.



Shipping Time :



● FedEx : 2-4 business days
● UPS : 2-5 business days
● DHL : 2-6 business days
● Shipment by Sea : 20-25 business days



Payment Method :



● PayPal (Online)

● Credit / Debit Card (Online)

● ABA Routing (US Local)

● T/T Wire Transfer (International)



Returns & Warranty :



● 1-Year Warranty

● 60-Day Returns

● 60-Day Exchange

● Limited Lifetime Warranty.

   Read full Return & Refund Policy



Net Term & Credit :



● Fibermart accept Net 30 and Net 60 payment terms, Contact Us for Credit Account by submit a credit form.



Volume Discount :



● Fibermart offers discount prices for large-volume order, Contact Sales Team for more details.



Customer Reviews

by Haris Link
Date Added: 07/08/2022
High quality dual rate 100g lr4, working great with CISCO, good job!

Rating: 5 of 5 Stars [5 of 5 Stars]
100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 10km Optical Transceiver Cisco QSFP-100G-LR4-D 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 10km Optical Transceiver Cisco QSFP-100G-LR4-D
